产品简介：
产品尺寸：外径36mm，厚度40mm，轴径4mm。
特征：双转向，信号功能，锁定保护，无级调速，低噪音，低电磁干扰，超长寿命10000-50000小时
| DEC3640 | Output Power 输出功率: 2W~50W | Weight 重量: 145g (Approx.) |
Brushless DC Motor-Typical Application 直流无刷电机-典型应用 Home Application: White Goods, Small Appliance, Fanner, Coffee Machine, Milk Tea Machine 家用电器：白色家电，小家电，风扇，咖啡机，奶茶机 Medical Apparatus: Medical Pump, Surgery Tools, Medical Stirrer, centrifugal Machine 医疗器械：医疗泵，手术器械，搅拌器，离心机 Industry Equipment: Electric Valve, Actuator, Micro Pump 工业设备：阀门，致动器，微型泵 Business Equipment: Printer, Copier, Projector, ATM, Vending Machine 商业设备：打印机，复印机，投影机，ATM机，售卖机 Personal Care: Hair Dryer, Electric Shaver, Massager 个人护理：风筒，电动须刨，按摩器 | |||
Model 型号 | 电压 Voltage(V) | No Load 空载 | Rated Load 额定负载 | Stall 堵转 | ||||||
Operating Range | Rated | Speed (rpm) | Current (A) | Torque (mNm) | Speed (rpm) | Current (A) | Output P. (W) | Torque (mNm) | Current (A) | |
DEC3640-S01 | 8-26 | 12 | 2360 | 0.14 | 25.5 | 1830 | 0.69 | 4.9 | 174.10 | 2.5 |
DEC3640-S02 | 8-26 | 12 | 7930 | 0.56 | 19.62 | 6800 | 1.89 | 13.97 | 83.22 | 3.0 |
DEC3640-S03 | 8-26 | 24 | 6140 | 0.26 | 23.5 | 5190 | 0.85 | 12.8 | 229.05 | 2.5 |
DEC3640-S04 | 8-26 | 24 | 16020 | 0.36 | 9.81 | 14940 | 0.98 | 15.35 | 90.68 | 2.5 |
DEC3640-S05 | 8-26 | 24 | 27685 | 0.47 | 19.62 | 22191 | 2.88 | 45.59 | 98.89 | 5.0 |
DEC3640-S06 | 12-40 | 36 | 20686 | 0.29 | 18 | 16726 | 1.30 | 31.53 | 94.02 | 2.5 |
DEC3640-S07 | 8-26 | 24 | 7046 | 0.28 | 56.00 | 5156 | 1.80 | 30.23 | 208.79 | 2.5 |
Characteristic: CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 10000-50000hrs 特征：双转向，信号功能，锁定保护，无级调速，低噪音，低电磁干扰，超长寿命10000-50000小时
Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement. 注意：上述规格仅针对特定客户，电压、扭矩、转速、电流、功率、输出轴的特征和尺寸等都可以按照客户的特殊要求进行调整。 |
Outline Drawing 外形图:
Usable machine screw length 4.0mm max. from motor mounting surface | Unit: Millimeter |
Performance Curve 性能曲线:
DEC3640-S01 12V | DEC3640-S05 24V |
